Scansilc 1824


The Scansilc 1824 like the Scansilc 2430 and 3643,  is a lightweight panel featuring a direct deposit A-Csl screen and developing 76 micron high definition images. The panel is rated to IPx7 water resistance and drop tested to 1 metre. This ruggedised x-ray system is designed for a range of security field applications including suspect package investigation, Bomb Disposal, EOD, baggage checks, searching for firearms or contraband material and counter-surveillance.

The Scansilc 1824  imager is only 2.18 cm thick. Unlike other most other x-ray systems that come from the medical field, Scansilc panels are specially designed to be high shock and impact tolerant with dust and water resistance to IP67.

Product Overview:

  • Active Area:175 x 223 mm
  • Physical Dimensions: 265 x 215 x 21.8 mm
  • Image Panel Weight: 1.7 kg
  • Pixel Pitch: 76 micron
  • Battery performance: 6 hours (standby)/4 hours (operational)
  • Battery performance: 6 hours (standby)/4 hours (operational)
  • Water resistant to IPx7
  • Search/ C-IED/EOD / Weapons investigation /TSCM
