12.5mm Recoilless Waterjet Disruptor

The 12.5mm Recoilless Waterjet Disruptor has been purposefully designed to effectively disrupt small devices and packages, measuring up to 10 x 15 x 24 cm and weighing a total of 226.8 grams. When utilizing an X-ray for interrogation, successful disruption of larger packages can be achieved. This disruptor is particularly suited for CBRNE (Chemical, Biological, Radiological, Nuclear, Explosive) devices that require stringent containment measures. Additionally, with its precise targeting capabilities, it can deliver an accurate strike on the initiator within a package. The disruptor is highly compatible with small robotic platforms and excels in deployment within tight spaces, such as under seats in cinemas, stadiums, and airplanes.

The maximum recommended standoff distance for the 12.5mm Recoilless Waterjet Disruptor is 1 meter, depending on the target.

General Specification

  • Bore diameter: 12.5mm
  • Total length: 32 cm
  • Total weight: 2.0 kg
  • Height on camera tripod: 183 cm maximum
  • Composition: Stainless Steel and Aluminium
  • Ignition voltage: P-Series Blasting Machine; 24 volts; 1 amp
  • Laser system: 12.5mm Single Laser Pointer Assembly
  • Liquid projectile: 25 mL
  • Liquid load: 50 mL
  • Peak liquid projectile velocity: 400 m/s
  • Kinetic energy: 1.1 kJ
  • Recoil reduction: 97%
  • Vertical adjustment: 180˚
  • Horizontal adjustment: 360˚, for multipurpose positioning
  • Barrel composition: Stainless Steel
  • Barrel length: 25 cm
  • Barrel weight: 0.7 kg

Ammunition

  • Electrically primed – 12, 16 grain
  • Percussion primed – 12, 16 grain
  • 12.5mm Avon Frangible
  • 12.5mm Flathead Steel Slug
