Scansilc 2430



The Scansilc 2430 EOD like the Scansilc 3643 and 1824,  is a lightweight panel featuring a direct deposit A-Csl screen and developing 76 micron high definition images. The panel is rated to IPx7 water resistance and drop tested to 1 metre. This ruggedised x-ray system is designed for a range of security field applications including suspect package investigation, Bomb Disposal, EOD, baggage checks, searching for firearms or contraband material and counter-surveillance.

The Scansilc 2430 EOD Imagers is only 2.15 cm thick. Unlike other most other x-ray systems that come from the medical field, Scansilc panels are specially designed to be high shock and impact tolerant with dust and water resistance to IP67 and a load bearing weight of 170 kgs. There are no moving parts or scanning mechanisms inside the panels.The panels themselves incorporate unique intelligent processing and communications technology (that competitors build into a separate interface box), their unique Pb internal shielding provides resilience, and you get superb 8.5 hour power from each of the 2 batteries

Product Overview:

  • Imaging area: 233(w) x 291 (h) mm
  • Physical Dimensions: 327.5 x 322.5 x 21.5mm
  • Image Panel Weight: 2.8 kgs
  • Compact a-CsI imager. Format 24 x 30 cm
  • Pixel Pitch: 76 micron
  • Resolution: 6.5 lp/mm
  • Drop Tested: Over 1m
  • Time taken to deploy and x-ray < 2 mins
  • Fast x-ray image receive time: 7-12 seconds
  • Wireless operation as standard with cable backup
  • 8.5 hours standby battery operation.
  • Water resistant to IPx7
  • Colourised Dual Energy material filtering
  • Compatible with windows tablet or laptop
  • Search/ C-IED/EOD / Weapons investigation /TSCM
